實際面板尺寸PANEL | 65” |
長寬比率Aspect Ratio | 16:9 |
最高解析度Resolution(maximum) | 1920X1080 |
亮度Max brightness | 350cd/㎡ (typical) |
點距 Dot pitch(mm) | 0.7440mm x 0.7440mm x RGB |
顯示顏色 Display Color | 10 bit, 1.07B |
可視角度 ( H/V ) View angel | +-178度 |
訊號源 Input signal | 15Pin D-Sub, HDMI, USB |
垂直/水平頻率 v/h frequency | 50-75Hz / 31-64KHz |
反應時間 Reponse time tr / tf | 6.5ms |
可視範圍 Display Area | 1428.5(H) x 803.5(V) |
對比 Max contrast ratio | 4000:1 (typical) |
相容數位訊號Compatible digital signal | 480p,525i,525P,720P,1080i,1080p高畫質數位 FULL HDTV信號 |
重量(公斤)Weight(kg) | 40KG |
尺寸Dimensions(mm) | L1502.5 x D83.9 x H877.5 mm |
操作電壓 Max power consumption | INPUT 100~240VAC 50/60HZ 1.7A |
聲音輸出 AUDIO OUTPUT | 10WX2 |
操作環境 Operation Environment | 溫度(temperature) -20-50 濕度(humidity) 5%-95% |
消耗功率 Power Consumption | 待機(STANBY) 5W,使用(WORKING) 120-140W |
保固期限 warranty | 保固1年 |
壁掛式 Wall mount | W400 x H300mm |
觸控點數 | 多點 |
